QZD-400A Cable cutter

◇After many years of research and development, our company company has produced the brand new desigh "full automatic reset"
patented product for new generation of intelligent high-tech manual hydraulic press plier to make users do things with facility during
their work and experience the advantage of hydraulic tool and its automatic device. Come on to have a try
◇German high and new technology, novel design of LISIDA
◇Full automatic reset can replace safety device and save the time of manual pressure release
◇Manual pressure release button can be loosened during the pressing course and can reset rapidly
◇Built-in combined type oil valve is convenient for maintenance with less malfunction;
◇It's head part adopts open type and bolt bar type, It is handy and solid and can rotate freely at 360 degrees of angle

Item No	Crimping range	Crimping force	Stroke	Weight	Standard dies	Packaging & Size	Type
QZD-400A	16-400 mm²	10 ton	16 mm	6.5Kg	16,25,35,50,70,95,120, 150 185,240,300,400 mm²	690×250×120 mm	(Open type)
